VLI201094-N Four point contact ball bearing RKS.22 0941 slewing ring bearings 984x1198x56mm luoyang bearing RK6-37N1Z

Place of Origin Luoyang,China
Brand Name YDPB
Certification ISO
Model Number VLI201094-N
Minimum Order Quantity 1PCS
Price 1$
Packaging Details bearing+thin plastic film+waterproof paper+thin foam+carton/wooden cases
Delivery Time 5-7days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model VLI201094-N Material 50Mn Or According To You
Structure Four Point Contact Ball Dimension 984x1198x56mm
Application Manipulators Name INA Four Point Contact Ball Slewing Rings
Leave a Message
Product Description

VLI201094-N Four point contact ball bearing RKS.22 0941 slewing ring bearings 984x1198x56mm luoyang bearing RK6-37N1Z

  • Structure:Cross roller
  • Gear teeth: internal
  • Seals type:double seals
  • Material: 50Mn/ custom made
  • For light duty industrial manipulator or precision robotics.

Structure and Parameters:

VLI201094-N  Four point contact ball bearing RKS.22 0941 slewing ring bearings 984x1198x56mm luoyang bearing RK6-37N1Z 0

VLI Four point contact bearing (Internal gear teeth)

Models d (mm) D (mm) H (mm)
VLI200414-N 325 518 56
VLI200544-N 444 648 56
VLI200644-N 546 748 56
VLI200744-N 648 848 56
VLI200844-N 736 948 56
VLI200944-N 840 1048 56
VLI201094-N 984 1198 56


Equivalent Models

INA SKF KAYDON IMO
VLI200414-N RKS.22 0411 RK6-16N1Z 92-20 0413/1-37212
VLI200544-N RKS.22 0541 RK6-22N1Z 92-20 0541/1-37222
VLI200644-N RKS.22 0641 RK6-25N1Z 92-20 0641/1-37232
VLI200744-N RKS.22 0741 RK6-29N1Z 92-20 0741/1-37242
VLI200844-N RKS.22 0841 RK6-33N1Z 92-20 0841/1-37252
VLI200944-N RKS.22 0941 RK6-37N1Z 92-20 0941/1-37262
VLI201094-N RKS.22 1091 RK6-43N1Z 92-20 1091/1-37272
INA Rollix TGB Rothe Erde
VLI200414-N 22-0411-01 I.505.20.00.C 232.20.0400.013
VLI200544-N 22-0541-01 I.650.20.00.C 232.20.0500.013
VLI200644-N 22-0641-01 I.750.20.00.C 232.20.0600.013
VLI200744-N 22-0741-01 I.850.20.00.C 232.20.0700.013
VLI200844-N 22-0841-01 I.950.20.00.C 232.20.0800.013
VLI200944-N 22-0941-01 I.1050.20.00.C 232.20.0900.013
VLI201094-N 22-1091-01 I.1200.20.00.C 232.20.1000.013



Drawings and other parameters ,pls contact us free, thanks

Market:
After years of development ,our products have been sent out to Germany ,Italy, Spain, Romania,Belgium,Israel,Russia,Korea,Mexico,India etc. Good quality and Service earn the constant supports from all our customers. any of your questions will be welcomed here any time.
Payment Terms:
Most of our customers use T/T( 40% in advance, Balance before shippment), Western Union ,Money Gram, for larger amount consider LC, all can be negotiable.


Many other precision bearings series available


Online shopping Address: www.ydpbbearings.com
