RU42UUCC0P4 ru series cross cylindrical roller bearing china 350X540X45mm

Place of Origin Luoyang,China
Brand Name YDPB
Certification ISO
Model Number RU42UUCC0P4
Minimum Order Quantity 1PCS
Price 1$
Packaging Details bearing+thin plastic film+waterproof paper+thin foam+carton/wooden cases
Delivery Time 5-7days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model RU42UUCC0P4 Material GCr15SiMn
Structure Crossed Cylindrical Roller Bearings Dimension 350X540X45mm
Application Robots Arm Name Cross-roller Slewing Ring Bearing
Leave a Message
Product Description



Model number- RU42UUCC0 P4
Inner ring(mm)- 20
Outer ring(mm)- 70
Width(mm)- 12
Weight(Kg)- 0.29
Materials- GCR15/GCR15SiMn
Precision grade- P5/P4/P2
Lubrication type- Grease lubrication
Rotating part- Inner ring/Outer ring
Load direction- Multi-load
Structure- Integrated Inner/Outer Ring
precision level- P4,P2
Seals- can be double side (UU)
Clearance- CC0 or C0


Other models:
RU42,RU66,RU85,RU124(G)(X),RU148(G)(X),RU178(G)(X),RU228(G)(X),
RU297(G)(X),RU445(G)(X)

RU42UUCC0P4 ru series cross cylindrical roller bearing china 350X540X45mm 0

shaft diameter Identification number Main dimensious shoulder height Basic load rating (radial) weight
Inner diameter outer diameter Roller pitch circle diameter
width
Greasing hole∮ Chamfer
R(min)
ds Dh C Co Kg
d D DP B/B1 KN KN
35 RU66 35 95 66 15 3.1 0.6 59 74 17.5 22.3 0.62
55 RU85 55 120 85 15 3.1 0.6 79 93 20.3 29.5 1
80 RU124(G) 80 165 124 22 3.1 1 114 134 33.1 50.9 2.6
RU124X
90 RU148(G) 90 210 147.5 25 3.1 1.5 133 162 49.1 76.8 4.9
RU148X
115 RU178(G) 115 240 178 28 3.1 1.5 161 195 80.3 135 6.8
RU178X
160 RU228(G) 160 295 227.5 35 6 2 208 246 104 172 11.4
RU228X
210 RU297(G) 210 380 297.3 40 6 2.5 272 320 156 281 21.3
RU297X
350 RU445(G) 350 540 445.4 45 6 2.5 417 473 222 473 35.4
RU445X


Market:
After years of development ,our products have been sent out to Germany ,Italy, Spain, Romania,Belgium,Israel,Russia,Korea,Mexico,India etc. Good quality and Service earn the constant supports from all our customers. any of your questions will be welcomed here any time.

Features of RU series robotics bearings
1.Can bear comprehensive load e.g radial ,axial and overturn load .
2.Thin section bearings save installation space
3.High rotary positioning precision
4.Application area:robot arm,revolute joints,chassis etc parts.


More related products we have in stock
YRTS High speed rotary table bearings ,YRTM with angle measuring system bearings,ZKLDF SERIES ROTARY TABLE BEARING,Crossed roller bearing , Thin section bearing , Turntable bearing , Roller Bearing ,Bearing ,Slewing bearing ,Robotic bearing ,Rotary Table Bearing , YRT Rotary Table Bearing ,Angular Contact Ball Bearing , Ceramic bearings.
