XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm

China XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm supplier
XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm supplier XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm supplier XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm supplier XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm supplier

Large Image :  XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm

Product Details:

Place of Origin: made in china
Brand Name: YDPB
Model Number: XU300515

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 1$
Packaging Details: bearing+thin plastic film+waterproof paper+thin foam+carton/wooden cases
Delivery Time: 5-7days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000pcs/month
Contact Now
Detailed Product Description
Model: XU300515 Material: GCr15/GCr15SiMn
Structure: Single Row Crossed Cylindrical Roller Dimension: 384x646x86mm
Application: Vertical Machining Center Name: Cross Roller Slewing Ring Bearings

Crossed Roller Bearings Parameters
Model number- XU300515
Inner ring(mm)- 384
Outer ring(mm)- 646
Width(mm)- 86
Weight(Kg)- 115
Materials- GCR15/GCR15SiMn
Precision grade- P5/P4/P2
Lubrication type- Grease lubrication
Rotating part- Inner ring/Outer ring
Load direction- Multi-load
Structure- Integrated Inner/Outer Ring
Series Model NO..
XU050077,XU060094,XU060111,XU080120,XU080149,XU120179,XU120222,XU160260,XU080264,XU160405,XU080430,XU300515.
Related moldes.
XSU080168bearings,XSU080188bearings,XSU080218bearings,XSU080258bearings,XSU080318bearings,XSU080398bearings,
Applications
Vertical machining center,vibratory grinding unit,tandem roller etc. high precision parts
Structure and Parameters:
XU300515 single row crossed rollers slewing bearing suppliers 384x646x86mm

SeriesModel
Number
Main dimensionsFixing Hole(Outer ing)Fixing Hole(Inner ing)Basic load rating
(Axial)
Basic load rating
(Radial)
Weight
Kg
Inner ring
d(mm)
Outer ring
D(mm)
Roller pitch
circle
dp(mm)
Width
B(mm)
Pitch of holes
φLa
Number
na
Pitch of holes
φLi
Number
ni
Ca KNCoa KNCr KNCor KN
XUXU050077401127722976-φ6.6566-M822.42914.314.21.4
XU0600945714094261206-φ9706-M832.537.520.718.42.4
XU06011176.2145.7911115.87133.18-φ6.988.98-φ6.93644.522.821.51.2
XU08012069170120301486-φ9906-M8565335.5264
XU080149101.6196.85149.622.22177.816-φ6.9115.816-φ6.963664032.53.6
XU120179124.52341793521412-φ11144.512-φ1111817975887
XU1202221403002223627012-M1617012-φ181332758513112
XU1602601913292604630520-φ1421520-φ1421235013517316
XU080264215.931126425.4295.312-φ8.7231.812-φ8.78511754576.9
XU1604053364744054645030-φ1436030-φ1427055017227025
XU0804303804804302646220-φ939820-M101102807013812
XU3005153846465158659818-φ2643218-φ267201370455670115


Drawings and other parameters ,pls contact us free, thanks

Market:
After years of development ,our products have been sent out to Germany ,Italy, Spain, Romania,Belgium,Israel,Russia,Korea,Mexico,India etc. Good quality and Service earn the constant supports from all our customers. any of your questions will be welcomed here any time.
Payment Terms:
Most of our customers use T/T( 40% in advance, Balance before shippment), Western Union ,Money Gram, for larger amount consider LC, all can be negotiable.
